ATSC 3.0 Standards


This standard specifies the physical layer and the Medium Access Control (MAC) layer for the ATSC 3.0 Dedicated Return Channel (DRC). The DRC physical layer specifies the uplink framing, baseband signal generation, random access, and downlink synchronization scheme. The DRC MAC layer specifies the MAC procedures, MAC PDU formats, and signaling schemes between the ATSC […]

Read More Download PDF File

A/300:2017, “ATSC 3.0 System”

Approved 19 October 2017

This Standard describes the ATSC 3.0 digital television system. ATSC 3.0 is a suite of voluntary technical Standards and Recommended Practices that is fundamentally different from predecessor ATSC systems and is therefore largely incompatible with them. This divergence from earlier design is intended to allow substantial improvements in performance, functionality, and efficiency sufficient to warrant […]

Read More Download PDF File

This document describes the system discovery and signaling architecture for the ATSC 3.0 physical layer. Broadcasters anticipate providing multiple wireless-based services, in addition to conventional broadcast television in the future. Such services may be time-multiplexed together within a single RF channel. The bootstrap provides a universal entry point into a broadcast waveform. The bootstrap employs […]

Read More Download PDF File

This Standard describes the RF/Transmission of a physical layer waveform. This waveform enables flexible configurations of physical layer resources to target a variety of operating modes. The intent is to signal the applied technologies and allow for future technology adaptation.

Read More Download PDF File

This standard specifies the protocol on the Studio-to-Transmitter Link (STL) from studio-side infrastructure to a Single Frequency Network (SFN) of Transmitters. It defines delivery protocols for ALP Transport. The document also defines possible interfaces among the studio infrastructure, for example the interconnection of the ATSC 3.0 Link Layer Protocol (ALP) and a Broadcast Gateway. This […]

Read More Download PDF File

A/330:2016, “Link-Layer Protocol”

Approved 19 September 2016

This standard defines the ATSC Link-Layer Protocol (ALP). ALP corresponds to the data link layer in the OSI 7-layer model. ALP provides a path to deliver IP packets, link layer signaling packets, and MPEG-2 Transport Stream (TS) packets down to the RF Layer and back, after reception. ALP also optimizes the proportion of useful data […]

Read More Download PDF File

This document specifies protocols used for delivery and synchronization of media and non-timed data in the ATSC 3.0 system. A/331 specifies the technical mechanisms and procedures pertaining to service signaling and IP-based delivery of a variety of ATSC 3.0 services and contents to ATSC 3.0-capable receivers over broadcast, broadband, and hybrid broadcast/broadband networks. The service signaling […]

Read More Download PDF File Download Zip File

A/332:2017, “Service Announcement”

Approved 6 December 2017

The normative portions of this document define a standard for announcement of services in an ATSC 3.0 broadcast. A component of A/332 is the accompanying schema.

Read More Download PDF File Download Zip File

The normative portions of this document define a standard for service usage reporting for ATSC 3.0.

Read More Download PDF File

A/334:2016, “Audio Watermark Emission”

Approved 19 September 2016

This document specifies the VP1 audio watermark for use with systems conforming to the ATSC 3.0 family of specifications. The document specifies the format in which the audio watermark resides in a PCM audio signal. Emission by a broadcaster of the audio watermark is optional.

Read More Download PDF File

A/335:2016 “Video Watermark Emission”

Approved 20 September 2016

The video watermark technology described in this document provides the capability to robustly embed ancillary data in the transmitted pixels of a video signal. It is intended to provide a data path for its ancillary data payload that can readily survive changes in video compression data rate, transcoding to other video compression codecs, and delivery over […]

Read More Download PDF File

This document specifies methods by which receivers may recover content that is available from a broadcaster, but not delivered directly to the receiver through the RF broadcast signal. This method may be useful in the use case when the receiver is connected to a set-top box via an HDMI cable and is only receiving uncompressed […]

Read More Download PDF File

A/337:2018, “Application Signaling”

Approved 2 January 2018

This document specifies mechanisms for signaling the properties of applications, including their lifecycle states, and also mechanisms for delivering activation notifications synchronized with a time base, so that the actions of applications can be synchronized accordingly. Accompanying schema is also provided. Section 4.3 of this document includes descriptions on the DWD (Distribution Window Description). Similar […]

Read More Download PDF File Download Zip File

A/338:2017, “Companion Device”

Approved 17 April 2017

This document specifies the communication protocol between an ATSC 3.0 primary device and an ATSC 3.0 companion device. In this context, the primary device is the primary receiver and is used to present the primary content. The companion device communicates with the primary device to present related, supplementary content, or even the same content as […]

Read More Download PDF File

A/341:2018, “VIDEO – HEVC”

Approved 28 August 2018.

This Standard describes the video coding constraints on ITU-T Rec. H.265 | International Standard ISO/IEC 23008-2 (“HEVC”) when it is used for video compression in the ATSC 3.0 Digital Television System. Any other video coding technologies in the ATSC 3.0 system are documented in their own ATSC Standard(s). A/300 provides references to the various video […]

Read More Download PDF File

This document specifies the common framework for ATSC 3.0 Audio. It is intended to be used in conjunction with the specific audio technologies described in subsequent parts of this Standard. The ATSC 3.0 audio system provides immersive and personalizable sound for television. It is not compatible with the audio system used in ATSC 1.0 service.

Read More Download PDF File

A/342 Part 2:2017, “AC-4 System”

Approved 23 February 2017

This document standardizes the AC-4 audio system for use in the ATSC 3.0 Digital Television System. It describes the characteristics of the AC-4 audio system and establishes a set of constraints on ETSI TS 103 190-2 for use within ATSC 3.0 broadcast emissions. The ATSC 3.0 audio system provides an enhanced feature set and improves […]

Read More Download PDF File

This document standardizes the MPEG-H Audio system for use in the ATSC 3.0 Digital Television System. It describes the characteristics of the MPEG-H Audio system and establishes a set of constraints on MPEG-H Audio for use within ATSC 3.0 broadcast emissions. The ATSC 3.0 audio system provides an enhanced feature set and improves upon the […]

Read More Download PDF File

This standard defines the required technology for closed caption and subtitle tracks over ROUTE-DASH and MMT transports. This includes the content essence and the packaging and timing.

Read More Download PDF File

This document describes the interactive content environment provided by an ATSC 3.0 receiver. This environment is comprised of a standard W3C User Agent with known characteristics, a WebSocket interface for obtaining information from the receiver and controlling various receiver functionality, and an HTTP interface for accessing files delivered over broadcast. This document also specifies the […]

Read More Download PDF File

This standard specifies the mechanisms for security and service protections in ATSC 3.0 systems.

Read More Download PDF File
